Whole House Multimedia Filter System

The Aqua Fresh Whole House Multimedia Filter System is designed to improve overall water quality by removing suspended solids, dirt, chlorine, organic matter, and odor-causing contaminants. It uses a combination of high-performance filter media such as sand, coconut shell activated carbon, garnet, and leaf mold to ensure clean, clear, and safe water throughout the house.

These filters are ideal as a pre-treatment for residential, commercial, and industrial water purification systems, ensuring protection for RO plants, softeners, and pipelines.

Specification:

• Water Flow Capacity: Available between 14 GPM up to 305 GPM (gallons per minute)

• FRP Vessel Sizes: 13×54, 1665, 2160, 24×69, 30×72, 36×73, 42×78, 63×103

• Control Valve: Clack Control Valve (sizes 1” up to 3”)

• Brine Tank Options: 100, 150, 200, up to 500 Liters

• Operating Cycles (custom models):

  • Backwash – hydraulic cleaning; up-flow

  • Slow rinse – displaces residual brine; down-flow

  • Brine refill – restores resin to sodium form; down-flow

  • Fast rinse – prepares resin/media bed for service cycle; down-flow
