Aqua Fresh DUPLEX Water Softener System

The Aqua Fresh DUPLEX Water Softener System is designed for continuous 24-hour operation, ensuring a constant supply of soft, scale-free water for residential, commercial, and industrial applications.

Equipped with a Clack control valve (USA), this system uses two resin columns that work alternately: one provides soft water while the other regenerates, guaranteeing non-stop operation.

By removing calcium, magnesium, iron, and manganese ions, this system prevents scale formation inside pipelines, boilers, chillers, cooling towers, and other industrial equipment—extending their life and improving efficiency.

Benefits

• Continuous supply of soft & safe water

• Protects industrial equipment from scale & corrosion

• Reduces maintenance and downtime

• Saves on detergents, soaps & chemicals

• Extends lifespan of plumbing, appliances, and machinery

• Automatic system – low maintenance, high performance

Technical Specifications

• Flow Rate: 14 GPM up to 305 GPM

• FRP Vessel Sizes: 13×54, 16×65, 21×60, 24×69, 30×72, 36×73, 42×78, 63×103

• Control Valve: Clack (USA) 1” up to 3”

• Brine Tank Sizes: 100L, 150L, 200L, up to 500L

🔄 Automatic Operation Cycles:

1. Backwash – Hydraulic cleaning (up-flow)

2. Slow Rinse – Displaces residual brine (down-flow)

3. Brine Refill – Restores resin to sodium form (down-flow)

4. Fast Rinse – Prepares resin for next service cycle (down-flow)

Applications

• Residential Villas & Compounds

• Hospitals & Clinics

• Hotels & Resorts

• Factories & Manufacturing Plants

• Cooling Towers & Boilers
